The GEYA GSR1-1-40DA is a single-phase solid state relay designed for industrial electrical control applications. Unlike mechanical relays, it uses semiconductor switching elements to provide fast, reliable, and maintenance-free switching of AC loads.
Key Features
- Solid state switching — no moving parts, for long service life and high reliability
- Zero-crossing switching — reduces electrical noise and stress during load switching
- Wide input control range — operates from a low-voltage DC control signal (3-32 VDC)
- Photoelectric isolation — high electrical isolation between control and load circuits (~2500 Vrms)
- Compact and durable — epoxy-filled housing resists shock, moisture, and corrosion
- CE certified — meets standard safety and quality requirements
Technical Specifications
| Specification | Details |
|---|---|
| Model | GEYA GSR1-1-40DA |
| Type | Single-phase Solid State Relay (SSR) |
| Control Voltage | 3-32 VDC (DC control) |
| Control Current | Approx. 5-15 mA |
| Rated Load Current | 40 A |
| Output Voltage Range | 24-480 VAC |
| Peak Voltage Capability | Up to 800-1200 VAC |
| Leakage Current (Off State) | ≤8 mArms |
| Saturation Voltage (On State) | ≤1.5 V |
| Switching Delay | ≤10 ms |
| Operating Temperature | -20 °C to +75 °C |
| Insulation Withstand | 2500 Vrms (input-output), 4000 Vrms (to housing) |
| Mounting | Bolt fixing |
| Approx. Size | 57.4 × 44.8 × 28 mm |
| Certifications | CE certified |
Applications
- Heater and temperature control systems
- Industrial machine and panel control
- High-cycle switching where mechanical relays wear out
Learn what makes this product unique and why it’s right for you.
The GEYA GSR1-1-40DA is a single-phase solid state relay designed for industrial electrical control applications. Unlike mechanical relays, it uses semiconductor switching elements to provide fast, reliable, and maintenance-free switching of AC loads.
Key Features
- Solid state switching — no moving parts, for long service life and high reliability
- Zero-crossing switching — reduces electrical noise and stress during load switching
- Wide input control range — operates from a low-voltage DC control signal (3-32 VDC)
- Photoelectric isolation — high electrical isolation between control and load circuits (~2500 Vrms)
- Compact and durable — epoxy-filled housing resists shock, moisture, and corrosion
- CE certified — meets standard safety and quality requirements
Technical Specifications
| Specification | Details |
|---|---|
| Model | GEYA GSR1-1-40DA |
| Type | Single-phase Solid State Relay (SSR) |
| Control Voltage | 3-32 VDC (DC control) |
| Control Current | Approx. 5-15 mA |
| Rated Load Current | 40 A |
| Output Voltage Range | 24-480 VAC |
| Peak Voltage Capability | Up to 800-1200 VAC |
| Leakage Current (Off State) | ≤8 mArms |
| Saturation Voltage (On State) | ≤1.5 V |
| Switching Delay | ≤10 ms |
| Operating Temperature | -20 °C to +75 °C |
| Insulation Withstand | 2500 Vrms (input-output), 4000 Vrms (to housing) |
| Mounting | Bolt fixing |
| Approx. Size | 57.4 × 44.8 × 28 mm |
| Certifications | CE certified |
Applications
- Heater and temperature control systems
- Industrial machine and panel control
- High-cycle switching where mechanical relays wear out
GEYA
by
GEYA
GEYA GSR1-1-40DA Solid State Relay (40A, DC Control)
- Regular price
- 290.00 ฿
- Sale price
- 290.00 ฿
- Regular price
-
390.00 ฿
Prices exclude 7% VAT · Full VAT invoice available
SKU: GEY-GSR1-1-40DA
Couldn't load pickup availability
Out of stock
